DOORS > ALUMINIUM DOORS> ALUMINIUM mb86si
Drutex Aluminium Door MB-86SI

Modern and resistant aluminium doors that stand out with high durability

Advantages

  1. Doors in MB86 SI system may be used in both  individual building and aluminum facades.

  2. Increased thermal insulation of MB-86 SI system achieved thanks to the application of an extra chamber in the thermal break.

  3. Very good heat transmittance coefficient (U-value) thanks to the application of thermal breaks.

  4. Big choice of colours in the standard colour range, enables to satisfy the most demanding clients

  5. The profile shape enables to obtain slim and durable structures of windows and doors.

  6. Tightness is ensured by the application of special gaskets made of a two-component EPDM synthetic rubber: solid and cellular, which guarantees resistance to ageing during years of exploitation as well as great thermal insulation.

  7. Wide range of filling thicknesses guarantees the possibility to apply any standard and non-standard glasses.

Technical Data

Spacer frame

Steel galvanized spacer frame in standard, optionally- Swisspacer Ultimate available in various colour options



Profile

The system profiles have a three-chamber structure with the structural depth of the door 77  mm with a thermal break made of polyamide, that is reinforced with fiberglass.



Gaskets

Glass and rebate gaskets made of EPDM, central gasket made of two-component EPDM synthetic rubber: solid and cellular



Colour range

According to the RAL color range and wood-grain coating from Aluprof ColorCollection



Fittings

3-point automatic espagnolette MACO; hinges made of drawn aluminum which stands out with great durability. Optionally lock with one point latch bolt.



Glass

Glass packages up to 55mm; in standard the one-chamber glass package with heat transfer coefficient Ug = 1,0 W/(m2K) according to the PN-EN674 norm; the possibility to apply a three-glass package with U= 0,5 W/(m2K) coefficient or a four-glass package filled with krypton and U=0,3 W/(m2K);   the possibility to apply glasses with increased acoustic insulation, tempered, safety, anti-burglary, ornament or solar protective.

ALU Sandwich Panel

Door panels made of aluminum, 36-mm thick (or 77-mm for the MB-86SI system flushed on both sides) are Drutex original solutions. They consist of two layers of 2.5 millimeter aluminum sheets on both sides of the door. Inside there is XPS foam divided by 1-millimeter aluminum sheet. This cutting-edge solution determined great energy efficiency and strength parameters of Drutex doors. The 28-mm thick glass (or 70 mm for the MB-86SI system flushed on both sides) applied in these solutions are exclusively own-produced. In the MB-86SI system there is a possibility to flush the panels with the door sash on the outside and on both sides.

ALU SANDWICH PANEL
ALU SANDWICH PANEL

MB-86SI - input panel

press to zoom
ALU SANDWICH PANEL
ALU SANDWICH PANEL

MB-86SI - flushed on one side

press to zoom
ALU SANDWICH PANEL
ALU SANDWICH PANEL

MB-86SI - flushed on both sides

press to zoom

Flush Panel Models

ALASKA 3 L_R
ALASKA 3 L_R
press to zoom
ALASKA 2
ALASKA 2
press to zoom
ALASKA 1
ALASKA 1
press to zoom
WASHINGTON ZERO
WASHINGTON ZERO
press to zoom
WASHINGTON WOOD L_R
WASHINGTON WOOD L_R
press to zoom
WASHINGTON POCKET
WASHINGTON POCKET
press to zoom
WASHINGTON 4
WASHINGTON 4
press to zoom
WASHINGTON 3 L_R
WASHINGTON 3 L_R
press to zoom
WASHINGTON 1
WASHINGTON 1
press to zoom
WASHINGTON 2
WASHINGTON 2
press to zoom
TEXAS WOOD L_R
TEXAS WOOD L_R
press to zoom
TEXAS L_R
TEXAS L_R
press to zoom
NEW YORK 2 L_R
NEW YORK 2 L_R
press to zoom
NEW YORK 1 L_R
NEW YORK 1 L_R
press to zoom
PENNSYLVANIA 2 L_R
PENNSYLVANIA 2 L_R
press to zoom
PENNSYLVANIA 4
PENNSYLVANIA 4
press to zoom
PENNSYLVANIA 5 L_R
PENNSYLVANIA 5 L_R
press to zoom
TEXAS C
TEXAS C
press to zoom
NEBRASKA L_R_C
NEBRASKA L_R_C
press to zoom
NEW YORK 1 C
NEW YORK 1 C
press to zoom
MONTANA WOOD
MONTANA WOOD
press to zoom
MONTANA 4
MONTANA 4
press to zoom
HAWAII 1
HAWAII 1
press to zoom
MONTANA 1
MONTANA 1
press to zoom
HAWAII 6 L_R
HAWAII 6 L_R
press to zoom
FLORIDA 1 L_R
FLORIDA 1 L_R
press to zoom
FLORIDA 2 L_R
FLORIDA 2 L_R
press to zoom
ARIZONA 1
ARIZONA 1
press to zoom
ARIZONA 2
ARIZONA 2
press to zoom
CALIFORNIA 1 C
CALIFORNIA 1 C
press to zoom
CALIFORNIA 1 R_L
CALIFORNIA 1 R_L
press to zoom
CALIFORNIA 2 R_L
CALIFORNIA 2 R_L
press to zoom
CALIFORNIA 2 C
CALIFORNIA 2 C
press to zoom
FLORIDA 3 L_R
FLORIDA 3 L_R
press to zoom
HAWAII 4
HAWAII 4
press to zoom
HAWAII 5 L_R
HAWAII 5 L_R
press to zoom
Model 1 Glass panel
Model 1 Glass panel

MB-86SI

press to zoom

Flush Panel Inox Models

TEXAS INOX C
TEXAS INOX C
press to zoom
PENNSYLVANIA INOX 3 L R
PENNSYLVANIA INOX 3 L R
press to zoom
PENNSYLVANIA INOX 2 L R
PENNSYLVANIA INOX 2 L R
press to zoom
NEBRASKA INOX L R C
NEBRASKA INOX L R C
press to zoom
PENNSYLVANIA INOX 1
PENNSYLVANIA INOX 1
press to zoom
OHIO INOX
OHIO INOX
press to zoom
MONTANA INOX 3 L R
MONTANA INOX 3 L R
press to zoom
MONTANA INOX 2
MONTANA INOX 2
press to zoom
KOLORADO INOX
KOLORADO INOX
press to zoom
MONTANA INOX 1
MONTANA INOX 1
press to zoom
FLORIDA INOX 1 L R
FLORIDA INOX 1 L R
press to zoom
HAWAII INOX 3
HAWAII INOX 3
press to zoom
HAWAII INOX 2
HAWAII INOX 2
press to zoom
ARIZONA INOX 1
ARIZONA INOX 1
press to zoom
CALIFORNIA INOX 1 LR
CALIFORNIA INOX 1 LR
press to zoom
CALIFORNIA INOX 1 C
CALIFORNIA INOX 1 C
press to zoom
CALIFORNIA INOX 2 C
CALIFORNIA INOX 2 C
press to zoom
CALIFORNIA INOX 2 L R
CALIFORNIA INOX 2 L R
press to zoom
HAWAII INOX 1
HAWAII INOX 1
press to zoom
ARIZONA INOX 2
ARIZONA INOX 2
press to zoom
ALASKA INOX 2
ALASKA INOX 2
press to zoom
TEXAS INOX L R
TEXAS INOX L R
press to zoom

Non- Flush Panel Models

WASHINGTON ZERO
WASHINGTON ZERO
press to zoom
TEXAS L_R
TEXAS L_R
press to zoom
TEXAS C
TEXAS C
press to zoom
PENNSYLVANIA 4
PENNSYLVANIA 4
press to zoom
PENNSYLVANIA 5 L_R
PENNSYLVANIA 5 L_R
press to zoom
PENNSYLVANIA 2 L_R
PENNSYLVANIA 2 L_R
press to zoom
NEW YORK 2 L_R_C
NEW YORK 2 L_R_C
press to zoom
NEBRASKA L_R_C
NEBRASKA L_R_C
press to zoom
HAWAII 1
HAWAII 1
press to zoom
MONTANA 1
MONTANA 1
press to zoom
FLORIDA 1 L_R
FLORIDA 1 L_R
press to zoom
CALIFORNIA 2 L_R
CALIFORNIA 2 L_R
press to zoom
ALASKA 1
ALASKA 1
press to zoom
ALASKA 2
ALASKA 2
press to zoom
ARIZONA 1
ARIZONA 1
press to zoom
CALIFORNIA 1 L_R
CALIFORNIA 1 L_R
press to zoom
CALIFORNIA 1 C
CALIFORNIA 1 C
press to zoom
CALIFORNIA 2 C
CALIFORNIA 2 C
press to zoom
ARIZONA 2
ARIZONA 2
press to zoom

Non- Flush Panel Inox Models

ALASKA INOX 1
ALASKA INOX 1
press to zoom
TEXAS INOX C
TEXAS INOX C
press to zoom
TEXAS INOX L_R
TEXAS INOX L_R
press to zoom
PENNSYLVANIA INOX 3 L_R
PENNSYLVANIA INOX 3 L_R
press to zoom
PENNSYLVANIA INOX 2 L_R
PENNSYLVANIA INOX 2 L_R
press to zoom
OHIO INOX
OHIO INOX
press to zoom
PENNSYLVANIA INOX 1
PENNSYLVANIA INOX 1
press to zoom
NEBRASKA INOX L_R_C
NEBRASKA INOX L_R_C
press to zoom
MONTANA INOX 3 L_R
MONTANA INOX 3 L_R
press to zoom
MONTANA INOX 2 L_R
MONTANA INOX 2 L_R
press to zoom
MONTANA INOX 1
MONTANA INOX 1
press to zoom
HAWAII INOX 3
HAWAII INOX 3
press to zoom
KOLORADO INOX
KOLORADO INOX
press to zoom
CALIFORNIA INOX 1 L_R_C-2.
CALIFORNIA INOX 1 L_R_C-2.
press to zoom
CALIFORNIA INOX 2 L_R_C-2.
CALIFORNIA INOX 2 L_R_C-2.
press to zoom
CALIFORNIA INOX 2 L_R_C-1.
CALIFORNIA INOX 2 L_R_C-1.
press to zoom
FLORIDA INOX 1 L_R
FLORIDA INOX 1 L_R
press to zoom
HAWAII INOX 1
HAWAII INOX 1
press to zoom
HAWAII INOX 2
HAWAII INOX 2
press to zoom
ARIZONA INOX 1
ARIZONA INOX 1
press to zoom
ARIZONA INOX 2
ARIZONA INOX 2
press to zoom
CALIFORNIA INOX 1 L_R_C-1.
CALIFORNIA INOX 1 L_R_C-1.
press to zoom
ALASKA INOX 2
ALASKA INOX 2
press to zoom
RAL Colour Chart

Painting technology of Drutex aluminium woodwork is among the top technologies available on the global market. It ensures corrosion protection even in the most aggressive sea and industrial environment. The anodal layer ensures perfect powder paint adhesion and it fully protects the structure against filiform corrosion.

Powder Coating

The powder paint that Drutex applies is from renowned producers with years of experience on the architecture market. Their coating stands out for perfect resistance to weather conditions, are easy to maintain and they ensure superb appearance for years.

Our collection includes timeless matt finishes, elegant structures, sophisticated metallic paint as well as special effects such as anodal paint and wood effect.



Advantages

Coating Quality and Resistance

Powder varnishing ensures a more uniform coating and higher resistance to abrasion, mechanical damage and UV radiation than the so called wet coating, which allows to maintain aesthetic qualities and colour durability for years

Ecology

The powder coating technology, thanks to the possibility to retrieve unused paint, is the most beneficial for environmental protection. Combined with the cutting edge technology and no need to use solvents, it ensures maximum safety also when it comes to ecology.



Wide Colour Range and Optional Coating Structures

The offer includes dozens of colours as well as structural coating, which enables a perfect arrangement of the building and product functionality (by giving smoothness or roughness)



Environmental Protection

While designing the paint shop environmental aspects were key importance to Drutex. Apart from prolonging lifespan of their products, they minimize impact on the environment through:

  • innovative systems or rotary doors in the oven that minimizes heat loss

  • low temperature degreasing and digestion

  • their own waste water treatment plant complying with stringent EU requirements

  • cutting edge system of paint feeding ensuring almost 100% product use

  • close water circulation with the capacity of 12000 litres per hour

  • not using products containing Cr (VI)

Gloss and Matte Finish RAL 7016

Gloss and Matte Finish Anthracite RAL 70
