Every aspect of the MakroPro 2.0 series doors has been meticulously crafted based on a thorough understanding of the requirements of demanding professionals. Their innovative structural solutions set them apart in the market, ensuring easy installation and versatile applications across a wide range of industrial and public utility buildings.
​Advantages
ThermoSet™ as Standard
The ThermoSet™ thermal insulation kit enhances the door’s sealing capabilities, significantly reducing energy losses within the building. This feature comes standard with the MakroPro 2.0 series doors, distinguishing them from conventional options.
A Streamlined Installation System
Designed for efficiency, the MakroPro 2.0 doors minimize installation and maintenance time. Features like load-bearing cable adjustments, a 1,000 mm reference mark, "click" type seals, adjustable guides, an open drive unit enclosure, double fixing holes, and a crossbar with a gauge function all help reduce errors and expedite the installation process.
An Industrial Door That Redefines Expectations
Who says industrial doors must adhere to traditional designs? The MakroPro 2.0 ELH series doors can seamlessly integrate with your building's façade. Whether covered in wood, Corten sheets, stone, or plastic panels, these doors can blend perfectly with their surroundings, creating a cohesive aesthetic.
Versatile for Any Building Type
With 15 different track types available, the MakroPro 2.0 series doors can be customized to fit almost any structure. They can be installed in standard buildings, those with high ceilings, or even spaces with low ceilings, providing flexibility for various architectural needs.
Characteristics and Features
MakroPro 2.0
The MakroPro 2.0 doors are made of 40 [mm] thick warm steel panels infilled with polyurethane foam.
- The standard accessories include the ThermoSet™ gasket kit: four-chamber, double-lip thermal side gaskets; double-lip top gasket; corner gaskets.
- Panel heat transfer coefficient Up = 0.48 [W/m2xK].
- Thickness of the opening frame 2 [mm] / guide 2 [mm].
- Panel side covers and reinforcements in door leaf colour.
- Quiet guiding rollers with a bush fitting.
- Double safety device for tracks preventing guiding rollers from derailing.
- Protection: cable break safety device (2 pcs.), spring break safety device (per each spring).
- Guaranteed number of cycles 25,000, optionally: 50,000, 100,000, and more than 100,000.
- Watertightness class 2.
- Wind load resistance class 3.
- Air permeability class 4.
- Sound insulation Rw=23/24 [dB] (without a wicket door / with a wicket door).
- Operating noise of the door: 24/36 [dB] (with an electric drive unit 8.60 FU / SE9).
- Reaction to fire NFP: B, s2, d0.
- The manually-operated door is fitted with a sliding bolt.
MakroPro ALU 2.0
The doors are made of 40 [mm] thick aluminium panels without a thermal break, infilled with acrylic glazing. Steel bottom panel.
- The standard accessories include the ThermoSet™ gasket kit: four-chamber, double-lip thermal side gaskets; double-lip top gasket; corner gaskets.
- Thickness of the opening frame 2 [mm] / guide 2 [mm].
- Panel reinforcement in the door leaf colour.
- Quiet guiding rollers with a bush fitting.
- Double safety device for tracks preventing guiding rollers from derailing.
- Protection: cable break safety device (2 pcs.), spring break safety device (per each spring).
- Guaranteed number of cycles 25,000, optionally: 50,000, 100,000, and more than 100,000.
- Watertightness class 2.
- Wind load resistance class 3.
- Air permeability class 4.
- Sound insulation Rw=23/25 [dB] (without a wicket door / with a wicket door).
- Reaction to fire NFP: B, s2, d0.
- The manually-operated door is fitted with a sliding bolt.
MakroPro ALU 2.0
The doors are made of 40 [mm] thick aluminium panels with a thermal break, infilled with acrylic glazing. Steel bottom panel.
- ThermoSet™ gasket kit: four-chamber, double-lip thermal side gaskets; double-lip top gasket; corner gaskets.
- Heat transfer coefficient – as provided on the door nameplate.
- Thickness of the opening frame 2 [mm] / guide 2 [mm].
- Panel reinforcement in the door leaf colour.
- Quiet guiding rollers with a bush fitting.
- Double safety device for tracks preventing guiding rollers from derailing.
- Protection: cable break safety device (2 pcs.), spring break safety device (per each spring).
- Guaranteed number of cycles 25,000, optionally: 50,000, 100,000, and more than 100,000 cycles. - Watertightness – class 3. - Air permeability – class 4.
- Sound insulation Rw=23 [dB].
- Wind load resistance – class 4.
- The manually-operated door is fitted with a sliding bolt.
MakroPro 2.0 ELH
Façade door
The MakroPro 2.0 ELH door is designed to accommodate custom infills, allowing its exterior to perfectly align with the vision of the designer or investor.
The options are nearly limitless. Whether covered in tiles, slate, or plastic panels, you can seamlessly integrate the door into the building’s façade, creating a strikingly uniform appearance. This versatility offers architects and businesses the chance to showcase their commitment to aesthetics and attention to detail.
